CS16809, yüksek performans, olağanüstü kullanılabilirlik ve ölçeklenebilirlik ile veri merkezlerinin gereksinimlerini karşılamak üzere tasarlanmıştır. 432*10GE port, 144*40GE veya 72*100GE portla sektördeki 14U kasada en yüksek kapasiteli 10GE, 40GE ve 100GE portları sunan 2 yönetim yuvası ve 9 genişleme yuvasına sahiptir.

CS16809, veri merkezi veya kampüs ağının ana katmanı ve IP büyükşehir ağlarının çekirdek / toplanması için idealdir.

Model	CS16809
Slot	2 management slots 4 fabric card slots 9 business slots
Business Ports	1GE : MAX 432 10G : MAX 432 40G: MAX 144
Performans
Anahtarlama Kapasitesi	10.24Tbps
İletim Hızı	7618Mpps
MAC Tablosu	288K-400K
Yönlendirme Tablosu	IPv4 8K / IPv6 4K
VLAN Tablosu	4K
Özellikler
Sistem Yapısı	CLOS
İletim	Storage and Forwarding IEEE802.3(10Base-T) IEEE802.3u(100Base-TX) IEEE802.3z(1000BASE-X) IEEE802.3ab(1000Base-T) IEEE802.3ae(10GBase) Loopback Interface 9k Jumbo Frame Port Loopback Detection LLDP and LLDP-MED UDLD
	LACP 802.3ad, max 128 group trunks with max 8 ports for each trunk Link Aggregation by manual
	IEEEE802.1d(STP) IEEEE802.1w(RSTP) IEEEE802.1s(MSTP) Max 48 instances Root Guard BPDU Guard BPDU Forwarding
	One to one or any to one mirror Mirror cross business cards RSPAN
	IGMP v1/v2/v3, IGMP v1/v2/v3 Snooping, IGMP Proxy ICMPv6, ND, ND Snooping, MLDv1/v2, MLDv1/v2 Snooping
	GVRP Port/ MAC/ IP Segment/ Portocol/ Voice/ Private/ VLAN support Multicast VLAN Register/MVR for IPv4 and IPv6
	Port-based 802.1Q, 4K VLAN QinQ and Selective QinQ
	DFI/Broadcast/Multicast Stormcontrol
	Binding(IPv4/IPv6), IP Source Guard MAC Filter, MAC Limit
	IP Source Guard
	Port Binding(IPv4 /IPv6)
	Support Smart Link (or named Flexible Link)
L3 Özellikleri	IP Protocol(IP support both of IPv4 and IPv6)
	Default Routing, Static Routing, Blackhole Route, VLSM and CIDR,
	RIPv1/V2, OSPFv2, BGP4, support MD5 Authentication LPM Routing
	OSPFv3, BGP4+ support
	Policy based Routing(PBR) for IPv4 and IPv6
	Support 4 byte BGP AS number
	Support GR for OSPF and BGP
	VRRP, VRRP v3
	DVMRP, PIM-DM, PIM-SM, PIM-SSM MSDP(Multicast Source Discovery Protocol) Static Multicast Route Multicast Edge Configure Any cast RP for IPv4 and IPv6 PIM-SM/DM/SSM for IPv6,  6 to 4 Tunnels, configured Tunnels, ISATAP Multicast Receive Control Illegal Multicast Source Detection
	URPF for IPv4 and IPv6
	BFD
	ECMP(Equal Cost Multi-Path)with maxim 8 groups
	ARP Guard, Local ARP Proxy, Proxy ARP, ARP Binding, Gratuitous ARP, ARP Limit
Data Center Özellikleri	VSF TRILL* VEPA* SDN OpenFlow1.0/1.3* (support open controller Opendaylight,Floodlight,Ryu,Pox, etc.)
Tunnel Technical	Manual Configure IPv4/IPv6 tunnel 6to4 Tunnel ISATAP Tunnel GRE Tunnel
MPLS	255 VRF/VFI LDP L3 MPLS VPN L2 VLL/VPLS MPLS/VPLS Proxy Cross Domain MPLS VPN MPLS QOS
QoS	8 Hardware Queues per port
	Traffic Classification based on IEEE 802.1p, ToS, port and DiffServ
	SP, WRR, SWRR
	Traffic Shaping
	Rate Limit for Import and Export
	PRI Mark/Remark
	WRED
	2 buckets with dual rate and triply color mark
	Standard and Expanded ACL
	IP ACL and MAC ACL,
	ACL based on source/definition IP, MAC, L3 protocol, TCP/UDP port number, IP PRI(DSCP, ToS, Precedence), Time
	Ingress and Egress ACL
ACL-X	Time-Based Security Auto-negotiation
	ACL rules can be configured to port, VLAN, VLAN routing interfaces
	Can be used for QoS Classification
Anti-attack and Security	S-ARP: ARP Inspection, defense ARP-DOS Attack and Address Clone
	Anti-Sweep: prevent Ping Sweep
	S-ICMP: resist PING-DOS attack, ICMP unreachable attack
	S-Buffer: prevent DDOS attack
	Switch engine CPU protection
	Key message priority: secure processing of key legal messages
	Port credit: inspect illegal DHCP Server, Radius Server. Connection via credit port only
	Support URPF, avoid IP address clone
	All the above technologies efficiently prevent various DOS attack (e.g. ARP, Synflood, Smurf, ICMP attack), support ARP monitoring, defense Worm, Bluster, check sweep and raise alarm
DHCP	Support DCHP Client, Relay, Snooping, Option 82
	DHCP Server for IPv4 and IPv6
	DHCP v6 and DHCP Snooping v6
DNS	DNS Client DNS Proxy
Halka Protokolü	MRPP (Multi-Ring Protect Protocol)
Erişim Güvenliği	802.1X Port, MAC, username based Account based on time length and traffic Guest VLAN and Auto VLAN Work with private client can manage P2P traffic MAC Based AAA(Client free access) PPPOE/PPPOE+ forwarding
AAA	ADIUS AAA for IPV4 and IPv6 TACACS+ AAA
Konfigürasyon ve Yönetim	CLI, Telnet, WEB, SSH and SSL
	SNMPv1/v2c/v3
	MIB
	RMON 1, 2, 3, 9
Power Saving Technology	Reduce power consumption, improve cooling and reliability Flexible fan and port management to save power consumption
SysLog	Save Syslog and Trap to local device or server Max. 8 servers for Syslog or Trap receive
NMS	Strict Access Control by ACL and QOS
	Access the switch through AAA or Local Authentication
	SNTP and NTP
	Setup Time Zone and Summer Time
Supervision and Trouble Shooting	Supervise abnormity of task, memory, CPU, stack, switch chip, temperature and raise alarm Sflow IPFIX (IP Flow Information Export) Ping and Trace route command
Konfigürasyon Yönetimi	Configuration file storage Command operation log Dual Images and files startup FTP/TFTP server or client upgrade
OAM	802.3ah 802.1ag
Fiziksel
Ölçüler	444mm×753mm ×620.8mm (14U)
Bağıl Nem	10%~90%, non-condensing
Saklama Sıcaklığı	-40°C~70°C
Çalışma Sıcaklığı	0°C~45°C
Güç Kaynağı	AC: Input 90~264V, 50~60 Hz:
